VK1021

VK1021 | DN15-1/2″ | K80 | Standard Response | Pendent | XT1

VK1021

VK1021 — Product Variants

30 SKUs · 13 attributes

Product Variants

SAP number 23868AA
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish Brass
K_factor_metric 80
K_factor_nominal 5.6
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 1/2″
Size_2 1/2″
Temperature_rating 57

SAP number 23868AB
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish Brass
K_factor_metric 80
K_factor_nominal 5.6
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 1/2″
Size_2 1/2″
Temperature_rating 68

SAP number 23868AD
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish Brass
K_factor_metric 80
K_factor_nominal 5.6
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 1/2″
Size_2 1/2″
Temperature_rating 79

SAP number 23868AE
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish Brass
K_factor_metric 80
K_factor_nominal 5.6
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 1/2″
Size_2 1/2″
Temperature_rating 93

SAP number 23868AG
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish Brass
K_factor_metric 80
K_factor_nominal 5.6
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 1/2″
Size_2 1/2″
Temperature_rating 141

SAP number 23868AZ
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish Brass
K_factor_metric 80
K_factor_nominal 5.6
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 1/2″
Size_2 1/2″
Temperature_rating Open

SAP number 23868FA
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish Chrome
K_factor_metric 80
K_factor_nominal 5.6
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 1/2″
Size_2 1/2″
Temperature_rating 57

SAP number 23868FB
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish Chrome
K_factor_metric 80
K_factor_nominal 5.6
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 1/2″
Size_2 1/2″
Temperature_rating 68

SAP number 23868FD
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish Chrome
K_factor_metric 80
K_factor_nominal 5.6
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 1/2″
Size_2 1/2″
Temperature_rating 79

SAP number 23868FE
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish Chrome
K_factor_metric 80
K_factor_nominal 5.6
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 1/2″
Size_2 1/2″
Temperature_rating 93

SAP number 23868FG
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish Chrome
K_factor_metric 80
K_factor_nominal 5.6
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 1/2″
Size_2 1/2″
Temperature_rating 141

SAP number 23868FZ
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish Chrome
K_factor_metric 80
K_factor_nominal 5.6
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 1/2″
Size_2 1/2″
Temperature_rating Open

SAP number 23868JNA
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish ENT
K_factor_metric 80
K_factor_nominal 5.6
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 1/2″
Size_2 1/2″
Temperature_rating 57

SAP number 23868JNB
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish ENT
K_factor_metric 80
K_factor_nominal 5.6
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 1/2″
Size_2 1/2″
Temperature_rating 68

SAP number 23868JND
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish ENT
K_factor_metric 80
K_factor_nominal 5.6
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 1/2″
Size_2 1/2″
Temperature_rating 79

SAP number 23868JNE
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish ENT
K_factor_metric 80
K_factor_nominal 5.6
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 1/2″
Size_2 1/2″
Temperature_rating 93

SAP number 23868JNG
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish ENT
K_factor_metric 80
K_factor_nominal 5.6
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 1/2″
Size_2 1/2″
Temperature_rating 141

SAP number 23868JNZ
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish ENT
K_factor_metric 80
K_factor_nominal 5.6
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 1/2″
Size_2 1/2″
Temperature_rating Open

SAP number 23868MA/B
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish Black
K_factor_metric 80
K_factor_nominal 5.6
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 1/2″
Size_2 1/2″
Temperature_rating 57

SAP number 23868MA/W
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish White
K_factor_metric 80
K_factor_nominal 5.6
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 1/2″
Size_2 1/2″
Temperature_rating 57

SAP number 23868MB/B
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish Black
K_factor_metric 80
K_factor_nominal 5.6
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 1/2″
Size_2 1/2″
Temperature_rating 68

SAP number 23868MB/W
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish White
K_factor_metric 80
K_factor_nominal 5.6
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 1/2″
Size_2 1/2″
Temperature_rating 68

SAP number 23868MD/B
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish Black
K_factor_metric 80
K_factor_nominal 5.6
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 1/2″
Size_2 1/2″
Temperature_rating 79

SAP number 23868MD/W
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish White
K_factor_metric 80
K_factor_nominal 5.6
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 1/2″
Size_2 1/2″
Temperature_rating 79

SAP number 23868ME/B
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish Black
K_factor_metric 80
K_factor_nominal 5.6
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 1/2″
Size_2 1/2″
Temperature_rating 93

SAP number 23868ME/W
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish White
K_factor_metric 80
K_factor_nominal 5.6
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 1/2″
Size_2 1/2″
Temperature_rating 93

SAP number 23868MG/B
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish Black
K_factor_metric 80
K_factor_nominal 5.6
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 1/2″
Size_2 1/2″
Temperature_rating 141

SAP number 23868MG/W
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish White
K_factor_metric 80
K_factor_nominal 5.6
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 1/2″
Size_2 1/2″
Temperature_rating 141

SAP number 23868MZ/B
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish Black
K_factor_metric 80
K_factor_nominal 5.6
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 1/2″
Size_2 1/2″
Temperature_rating Open

SAP number 23868MZ/W
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish White
K_factor_metric 80
K_factor_nominal 5.6
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 1/2″
Size_2 1/2″
Temperature_rating Open

SAP number	Application_detail	Connection	Connection_type	Finish	K_factor_metric	K_factor_nominal	Main_material	Maximum_working_pressure	Position	Response	Size	Size_2	Temperature_rating
23868AA	Standard Coverage	Threaded	NPT	Brass	80	5.6	Brass	12	Pendent	Standard	1/2″	1/2″	57
23868AB	Standard Coverage	Threaded	NPT	Brass	80	5.6	Brass	12	Pendent	Standard	1/2″	1/2″	68
23868AD	Standard Coverage	Threaded	NPT	Brass	80	5.6	Brass	12	Pendent	Standard	1/2″	1/2″	79
23868AE	Standard Coverage	Threaded	NPT	Brass	80	5.6	Brass	12	Pendent	Standard	1/2″	1/2″	93
23868AG	Standard Coverage	Threaded	NPT	Brass	80	5.6	Brass	12	Pendent	Standard	1/2″	1/2″	141
23868AZ	Standard Coverage	Threaded	NPT	Brass	80	5.6	Brass	12	Pendent	Standard	1/2″	1/2″	Open
23868FA	Standard Coverage	Threaded	NPT	Chrome	80	5.6	Brass	12	Pendent	Standard	1/2″	1/2″	57
23868FB	Standard Coverage	Threaded	NPT	Chrome	80	5.6	Brass	12	Pendent	Standard	1/2″	1/2″	68
23868FD	Standard Coverage	Threaded	NPT	Chrome	80	5.6	Brass	12	Pendent	Standard	1/2″	1/2″	79
23868FE	Standard Coverage	Threaded	NPT	Chrome	80	5.6	Brass	12	Pendent	Standard	1/2″	1/2″	93
23868FG	Standard Coverage	Threaded	NPT	Chrome	80	5.6	Brass	12	Pendent	Standard	1/2″	1/2″	141
23868FZ	Standard Coverage	Threaded	NPT	Chrome	80	5.6	Brass	12	Pendent	Standard	1/2″	1/2″	Open
23868JNA	Standard Coverage	Threaded	NPT	ENT	80	5.6	Brass	12	Pendent	Standard	1/2″	1/2″	57
23868JNB	Standard Coverage	Threaded	NPT	ENT	80	5.6	Brass	12	Pendent	Standard	1/2″	1/2″	68
23868JND	Standard Coverage	Threaded	NPT	ENT	80	5.6	Brass	12	Pendent	Standard	1/2″	1/2″	79
23868JNE	Standard Coverage	Threaded	NPT	ENT	80	5.6	Brass	12	Pendent	Standard	1/2″	1/2″	93
23868JNG	Standard Coverage	Threaded	NPT	ENT	80	5.6	Brass	12	Pendent	Standard	1/2″	1/2″	141
23868JNZ	Standard Coverage	Threaded	NPT	ENT	80	5.6	Brass	12	Pendent	Standard	1/2″	1/2″	Open
23868MA/B	Standard Coverage	Threaded	NPT	Black	80	5.6	Brass	12	Pendent	Standard	1/2″	1/2″	57
23868MA/W	Standard Coverage	Threaded	NPT	White	80	5.6	Brass	12	Pendent	Standard	1/2″	1/2″	57
23868MB/B	Standard Coverage	Threaded	NPT	Black	80	5.6	Brass	12	Pendent	Standard	1/2″	1/2″	68
23868MB/W	Standard Coverage	Threaded	NPT	White	80	5.6	Brass	12	Pendent	Standard	1/2″	1/2″	68
23868MD/B	Standard Coverage	Threaded	NPT	Black	80	5.6	Brass	12	Pendent	Standard	1/2″	1/2″	79
23868MD/W	Standard Coverage	Threaded	NPT	White	80	5.6	Brass	12	Pendent	Standard	1/2″	1/2″	79
23868ME/B	Standard Coverage	Threaded	NPT	Black	80	5.6	Brass	12	Pendent	Standard	1/2″	1/2″	93
23868ME/W	Standard Coverage	Threaded	NPT	White	80	5.6	Brass	12	Pendent	Standard	1/2″	1/2″	93
23868MG/B	Standard Coverage	Threaded	NPT	Black	80	5.6	Brass	12	Pendent	Standard	1/2″	1/2″	141
23868MG/W	Standard Coverage	Threaded	NPT	White	80	5.6	Brass	12	Pendent	Standard	1/2″	1/2″	141
23868MZ/B	Standard Coverage	Threaded	NPT	Black	80	5.6	Brass	12	Pendent	Standard	1/2″	1/2″	Open
23868MZ/W	Standard Coverage	Threaded	NPT	White	80	5.6	Brass	12	Pendent	Standard	1/2″	1/2″	Open

Additional part numbers might be available. Please refer to the technical documentation or contact your local Viking sales office for more information.
