VK2021

VK2021 | DN20-3/4″ | K115 | Standard Response | Pendent | XT1

VK2021

VK2021 — Product Variants

30 SKUs · 13 attributes

Product Variants

SAP number 23876AA
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish Brass
K_factor_metric 115
K_factor_nominal 8
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 3/4″
Size_2 3/4″
Temperature_rating 57

SAP number 23876AB
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish Brass
K_factor_metric 115
K_factor_nominal 8
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 3/4″
Size_2 3/4″
Temperature_rating 68

SAP number 23876AD
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish Brass
K_factor_metric 115
K_factor_nominal 8
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 3/4″
Size_2 3/4″
Temperature_rating 79

SAP number 23876AE
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish Brass
K_factor_metric 115
K_factor_nominal 8
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 3/4″
Size_2 3/4″
Temperature_rating 93

SAP number 23876AG
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish Brass
K_factor_metric 115
K_factor_nominal 8
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 3/4″
Size_2 3/4″
Temperature_rating 141

SAP number 23876AZ
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish Brass
K_factor_metric 115
K_factor_nominal 8
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 3/4″
Size_2 3/4″
Temperature_rating Open

SAP number 23876FA
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish Chrome
K_factor_metric 115
K_factor_nominal 8
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 3/4″
Size_2 3/4″
Temperature_rating 57

SAP number 23876FB
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish Chrome
K_factor_metric 115
K_factor_nominal 8
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 3/4″
Size_2 3/4″
Temperature_rating 68

SAP number 23876FD
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish Chrome
K_factor_metric 115
K_factor_nominal 8
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 3/4″
Size_2 3/4″
Temperature_rating 79

SAP number 23876FE
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish Chrome
K_factor_metric 115
K_factor_nominal 8
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 3/4″
Size_2 3/4″
Temperature_rating 93

SAP number 23876FG
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish Chrome
K_factor_metric 115
K_factor_nominal 8
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 3/4″
Size_2 3/4″
Temperature_rating 141

SAP number 23876FZ
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish Chrome
K_factor_metric 115
K_factor_nominal 8
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 3/4″
Size_2 3/4″
Temperature_rating Open

SAP number 23876JNA
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish ENT
K_factor_metric 115
K_factor_nominal 8
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 3/4″
Size_2 3/4″
Temperature_rating 57

SAP number 23876JNB
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish ENT
K_factor_metric 115
K_factor_nominal 8
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 3/4″
Size_2 3/4″
Temperature_rating 68

SAP number 23876JND
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish ENT
K_factor_metric 115
K_factor_nominal 8
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 3/4″
Size_2 3/4″
Temperature_rating 79

SAP number 23876JNE
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish ENT
K_factor_metric 115
K_factor_nominal 8
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 3/4″
Size_2 3/4″
Temperature_rating 93

SAP number 23876JNG
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish ENT
K_factor_metric 115
K_factor_nominal 8
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 3/4″
Size_2 3/4″
Temperature_rating 141

SAP number 23876JNZ
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish ENT
K_factor_metric 115
K_factor_nominal 8
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 3/4″
Size_2 3/4″
Temperature_rating Open

SAP number 23876MA/B
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish Black
K_factor_metric 115
K_factor_nominal 8
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 3/4″
Size_2 3/4″
Temperature_rating 57

SAP number 23876MA/W
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish White
K_factor_metric 115
K_factor_nominal 8
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 3/4″
Size_2 3/4″
Temperature_rating 57

SAP number 23876MB/B
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish Black
K_factor_metric 115
K_factor_nominal 8
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 3/4″
Size_2 3/4″
Temperature_rating 68

SAP number 23876MB/W
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish White
K_factor_metric 115
K_factor_nominal 8
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 3/4″
Size_2 3/4″
Temperature_rating 68

SAP number 23876MD/B
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish Black
K_factor_metric 115
K_factor_nominal 8
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 3/4″
Size_2 3/4″
Temperature_rating 79

SAP number 23876MD/W
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish White
K_factor_metric 115
K_factor_nominal 8
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 3/4″
Size_2 3/4″
Temperature_rating 79

SAP number 23876ME/B
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish Black
K_factor_metric 115
K_factor_nominal 8
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 3/4″
Size_2 3/4″
Temperature_rating 93

SAP number 23876ME/W
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish White
K_factor_metric 115
K_factor_nominal 8
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 3/4″
Size_2 3/4″
Temperature_rating 93

SAP number 23876MG/B
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish Black
K_factor_metric 115
K_factor_nominal 8
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 3/4″
Size_2 3/4″
Temperature_rating 141

SAP number 23876MG/W
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish White
K_factor_metric 115
K_factor_nominal 8
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 3/4″
Size_2 3/4″
Temperature_rating 141

SAP number 23876MZ/B
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish Black
K_factor_metric 115
K_factor_nominal 8
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 3/4″
Size_2 3/4″
Temperature_rating Open

SAP number 23876MZ/W
Application_detail Standard Coverage
Connection Threaded
Connection_type NPT
Finish White
K_factor_metric 115
K_factor_nominal 8
Main_material Brass
Maximum_working_pressure 12
Position Pendent
Response Standard
Size 3/4″
Size_2 3/4″
Temperature_rating Open

SAP number	Application_detail	Connection	Connection_type	Finish	K_factor_metric	K_factor_nominal	Main_material	Maximum_working_pressure	Position	Response	Size	Size_2	Temperature_rating
23876AA	Standard Coverage	Threaded	NPT	Brass	115	8	Brass	12	Pendent	Standard	3/4″	3/4″	57
23876AB	Standard Coverage	Threaded	NPT	Brass	115	8	Brass	12	Pendent	Standard	3/4″	3/4″	68
23876AD	Standard Coverage	Threaded	NPT	Brass	115	8	Brass	12	Pendent	Standard	3/4″	3/4″	79
23876AE	Standard Coverage	Threaded	NPT	Brass	115	8	Brass	12	Pendent	Standard	3/4″	3/4″	93
23876AG	Standard Coverage	Threaded	NPT	Brass	115	8	Brass	12	Pendent	Standard	3/4″	3/4″	141
23876AZ	Standard Coverage	Threaded	NPT	Brass	115	8	Brass	12	Pendent	Standard	3/4″	3/4″	Open
23876FA	Standard Coverage	Threaded	NPT	Chrome	115	8	Brass	12	Pendent	Standard	3/4″	3/4″	57
23876FB	Standard Coverage	Threaded	NPT	Chrome	115	8	Brass	12	Pendent	Standard	3/4″	3/4″	68
23876FD	Standard Coverage	Threaded	NPT	Chrome	115	8	Brass	12	Pendent	Standard	3/4″	3/4″	79
23876FE	Standard Coverage	Threaded	NPT	Chrome	115	8	Brass	12	Pendent	Standard	3/4″	3/4″	93
23876FG	Standard Coverage	Threaded	NPT	Chrome	115	8	Brass	12	Pendent	Standard	3/4″	3/4″	141
23876FZ	Standard Coverage	Threaded	NPT	Chrome	115	8	Brass	12	Pendent	Standard	3/4″	3/4″	Open
23876JNA	Standard Coverage	Threaded	NPT	ENT	115	8	Brass	12	Pendent	Standard	3/4″	3/4″	57
23876JNB	Standard Coverage	Threaded	NPT	ENT	115	8	Brass	12	Pendent	Standard	3/4″	3/4″	68
23876JND	Standard Coverage	Threaded	NPT	ENT	115	8	Brass	12	Pendent	Standard	3/4″	3/4″	79
23876JNE	Standard Coverage	Threaded	NPT	ENT	115	8	Brass	12	Pendent	Standard	3/4″	3/4″	93
23876JNG	Standard Coverage	Threaded	NPT	ENT	115	8	Brass	12	Pendent	Standard	3/4″	3/4″	141
23876JNZ	Standard Coverage	Threaded	NPT	ENT	115	8	Brass	12	Pendent	Standard	3/4″	3/4″	Open
23876MA/B	Standard Coverage	Threaded	NPT	Black	115	8	Brass	12	Pendent	Standard	3/4″	3/4″	57
23876MA/W	Standard Coverage	Threaded	NPT	White	115	8	Brass	12	Pendent	Standard	3/4″	3/4″	57
23876MB/B	Standard Coverage	Threaded	NPT	Black	115	8	Brass	12	Pendent	Standard	3/4″	3/4″	68
23876MB/W	Standard Coverage	Threaded	NPT	White	115	8	Brass	12	Pendent	Standard	3/4″	3/4″	68
23876MD/B	Standard Coverage	Threaded	NPT	Black	115	8	Brass	12	Pendent	Standard	3/4″	3/4″	79
23876MD/W	Standard Coverage	Threaded	NPT	White	115	8	Brass	12	Pendent	Standard	3/4″	3/4″	79
23876ME/B	Standard Coverage	Threaded	NPT	Black	115	8	Brass	12	Pendent	Standard	3/4″	3/4″	93
23876ME/W	Standard Coverage	Threaded	NPT	White	115	8	Brass	12	Pendent	Standard	3/4″	3/4″	93
23876MG/B	Standard Coverage	Threaded	NPT	Black	115	8	Brass	12	Pendent	Standard	3/4″	3/4″	141
23876MG/W	Standard Coverage	Threaded	NPT	White	115	8	Brass	12	Pendent	Standard	3/4″	3/4″	141
23876MZ/B	Standard Coverage	Threaded	NPT	Black	115	8	Brass	12	Pendent	Standard	3/4″	3/4″	Open
23876MZ/W	Standard Coverage	Threaded	NPT	White	115	8	Brass	12	Pendent	Standard	3/4″	3/4″	Open

Additional part numbers might be available. Please refer to the technical documentation or contact your local Viking sales office for more information.
